OEM Pressure Sensors - Overview

All OEM pressure sensors are PCB-mountable and available for differential, relative and absolute pressure.

SensorsDescriptionLinks
AMS 5105 OEM pressure sensor series with ratiometric voltage output and two separate programmable switching outputs

Series AMS 5105 - Amplified OEM Pressure Sensor and two Switchs

  • Analog voltage output (0.5 .. 4.5 V) and two switching outputs
  • Individually programmable switching function
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Pressure ranges from 5 mbar .. 7 bar
AMS 5612 OEM pressure sensor series with ratiometric mV output

Series AMS 5612 - Compensated OEM Pressure Sensor

  • Differential voltage output (mV, unamplified)
  • Calibrated and temperature compensated
  • Completely analog, very fast response time
  • Pressure ranges from 0.15 .. 15 PSI / 20.68 mbar .. 1.034 bar
AMS 5812 OEM pressure sensor series with ratiometric voltage and I2C output

Series AMS 5812 - Pressure Sensor with Analog & I2C Output

  • Analog voltage output (0.5 .. 4.5 V) and digital I2C output
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • High precision (total error down to 0.5 %)
  • Pressure ranges from 0.075 .. 100 PSI / 5.17 mbar .. 6.895 bar
AMS 5915 digital OEM pressure sensor series with I2C output

Series AMS 5915 - OEM Pressure Sensor with I2C Output

  • Digital I2C output
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Excellent long term stability
  • Pressure ranges from 2.5 mbar .. 16 bar
AMS 6915 digital OEM pressure sensor series with I2C output

Series AMS 6915 - Mini OEM Pressure Sensor with I2C Output

  • Digital I2C output
  • Calibrated and temperature compensated output (-25.. 85 °C)
  • Compact Design, horizontal or vertical
  • Pressure ranges from 2.5 mbar .. 1 bar
AMS 6916 - 微型模拟电压信号输出的OEM压力传感器

Series AMS 6916 - Mini OEM Pressure Sensor with Analog Output (0.5 - 4.5 V)

  • Analog output(0.5 - 4.5 V)
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Compact Design, horizontal or vertical
  • Pressure ranges from 5 mbar .. 1 bar


Pressure Sensors Module - Overview

All PCB sensor modules for gage, absolute, (bidirectional) differential, barometric pressure .

SensorsDescriptionLinks
AMS 2710/11 - Pressure Sensor Module with 0 .. 5/10 V Output

Series AMS 2710/11 - Pressure Sensor Module with 0 .. 5/10 V Output

  • Pressure Sensor Module with 0 .. 5/10 V Output
  • Supply voltage: 8/12 .. 36 V
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Pressure ranges from 5 mbar .. 1 bar
AMS 2712 Pressure Sensor Module with 4 .. 20 mA Output

Series AMS 2712 - Pressure Sensor Module with 4 .. 20 mA Output

  • Current-loop output (4 .. 20 mA)
  • Supply voltage: 8 .. 36 V
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Pressure ranges from 5 mbar .. 1 bar


Pressure Transmitter - Overview

All pressure transmitters are available for differential, bidirectional differential, relative and absolute pressure.

SensorsDescriptionLinks
AMS 3011 miniaturized pressure transmitter series with voltage output.

Series AMS 3011 - Mini Pressure Transmitter with 0 .. 5 V Output

  • Amplified analog voltage output (0 .. 5 V)
  • Supply voltage: 8 .. 36 V
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Pressure ranges from 25 mbar .. 10 bar
AMS 3012 miniaturized pressure transmitter series with current output.

Series AMS 3012 - Mini Pressure Transmitter with current Output

  • Current-loop output (4 .. 20 mA)
  • Supply voltage: 8 .. 36 V
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Pressure ranges from 25 mbar .. 10 bar
AMS 4710/11 miniaturized pressure transmitter series AMS 4710/11 with voltage output.

Series AMS 4710/11 - Pressure Transmitter with Voltage Output

  • Amplified analog voltage output (0 .. 5/10 V)
  • Supply voltage: 8/12 .. 36 V
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Pressure ranges from 5 mbar .. 2 bar
AMS 4712 miniaturized pressure transmitter series AMS 4712 with 4 .. 20 mA current-loop output.

Series AMS 4712 - Pressure Transmitter with Current Output

  • Current-loop output (4 .. 20 mA)
  • Supply voltage: 8 .. 36 V
  • Calibrated and temperature compensated output (-25 .. 85 °C)
  • Pressure ranges from 5 mbar .. 2 bar
